Clearing Misfeeds
96
6
Removing Jammed Paper
The following procedure explains how to remove jammed paper.
Important
❒ The fusing section of this machine might be very hot. Caution should be taken
when removing misfed paper.
❒ When removing jammed sheets, take care to touch only those areas explicitly
indicated in the manual.
❒ Do not remove the fusing unit. Doing so will result in loss of print quality.
•When A is lit
• When B1 is lit
• When B4 is lit
ANR004S
ANR005S
ANR006S
To Next Page
