Buttontypes
Eachmenucontainsseveralmenubuttons.Eachbuttonshowsthefunctionofthebutton,
someofthemalsodisplaythecurrentparametersetting.Themajorityofthebuttonsin
eachmenuprovideoneormoreofthesefunctions.
aYoucanincreaseanddecreaseparametervaluesbyclickingthe[+]and[–]elds
onthebutton.
bYoucanchangeparametervaluesbyclickingonthebutton,holdingthemouse
depressed,andthenmovingthecursorsideways.
cYoucanchangeparametervaluesbymeansofthescrollwheelonthemouseor
trackball.
dYoucanenterparametervaluesfromthekeyboard(ifyouhaveone).
eYoucanselectparametervaluefromthebutton'ssubmenu.
fYoucanopenadedicateddialogbox.
Howtoselectanumericalparameterusingthe+/-buttons
1Movethecursortoeithersideofthebutton,and
observethatthebackgroundcolourchanges.
aClickontheleft
sideofthebuttontodecreasethenumericalvalue.
bClickontheright
sideofthebuttontoincreasethenumericalvalue.
Howtoselectanumericalparameterbymovingthecursorhorizontally
1Placethecursoronthemiddleofthebutton.
2Clickandholdtheleft
mousebuttondepressed.
3Movethecursorhorizontally:lefttodecreasethevalue,orrighttoincreaseit.
4Releasethemousebuttonwhentherequestedvalueisshown.
Howtoselectanumericalparameterbymeansofthescrollwheel
1Placethecursoronthemiddleofthebutton.
2Spinthescrollwheelineitherdirectiontoincrease
ordecreasethevalue.
3Releasethescrollwheelwhentherequestedvalueisshown.
Howtoselectanumericalparameterusingthekeyboard
1Clickthemiddlesectionofthebuttontoopena
texteld.
2Typethenumericalvalueintothetexteld.
Ifthenumericalvalueexceedsthepermittedrange
fortheparameter,theframeinthetexteldwillbered.
Youwillthennotbeabletokeepthatvalue.
3PresstheEnterkey.
134
351718/C
