SimradEK15
•0=cableisnotconnected
•1=cableisOK
•2=ashortcircuit,orthehydrophonecurrentistoolarge
18error=errordetected–0whennoerrorisdetected,anumber>0indicatesanerror
condition
19chksum=Thechecksumeldconsistsofa"*"andtwohexdigitsrepresentingthe
exclusiveORofallcharactersbetween,butnotincluding,the"$"and"*"characters
PSIMP-D1PISensordata
ThisproprietarySimradtelegramcontainsthetypeandcongurationofPSandPI
sensorsusedbytheexternalPIcatchmonitoringsystem.
Note
Thisdescriptionisnotcomplete.Forfurtherinformation,contactSimrad.
Format
$PSIMP,D1,tt,dd,M,U,SNo,MNo,C,V,CR,Q,
In,SL,NL,G,Cb,error*chksum<CR><LF>
Formatdescription
1PS=Talkeridentier(mandatory)
2IMP=Telegramidentier
3D1=Sentencespecier
4tt=Timeofday
5dd=Currentdate
6M=Measurementtype:
•D=Depth
•T=Temperature
•C=Catch
•B=Bottom
•N=Nosensor
•M=Marker
7U=unit,alwaysinSIunits
•M=depthanddistancemeasurements
•C=temperaturemeasurements
8SNo=Sensornumber
9MNo=Measurementnumber
10C=channel;thenumber(1to30)ofthecommunicationchannelforthecurrent
datasource
11V=value;themagnitudeofthecurrentsensormeasurement
262
351718/C
