Displayviews
Variabledepthline
ThislinemarkerisenabledintheEchogramdialog
boxontheActivemenu.
Whenenabledahorizontaldepthlineisplaced
whereveryouclickintheechogram.Thisistypically
usedtomeasurethewaterdepth,thedepthofaschool,
orevensingleîš¿sh.
Youcanclickontheline,keepthemousebuttondepressed,andthendragthelineup
ordown.
Relatedtopics
•Addinghorizontalmarkerstotheechogramonpage65
•Echogram;Linestabonpage208
Rangeotherlines
ThislinemarkerisenabledintheEchogramdialog
boxontheActivemenu.
ThisfeatureisusedwhenyousetupyourEK15with
bothasurfacerelatedandbottomrelatedechogram
shownsimultaneously.
Whenenabled,twohorizontallinesinthesurfaceechogramindicatetherangeselected
inthebottomechogram.
Relatedtopics
•Addinghorizontalmarkerstotheechogramonpage65
•Echogram;Linestabonpage208
Biomassline
ThislinemarkerisenabledintheEchogramdialog
boxontheActivemenu.
ThebiomassmaybemonitoredusingtheBiomassline.
Thebiomasslineisanextrathickbrightlycolouredline
thatisaddedtotheechogram.Thelinewillidentify
thevariationsinbiomass.
Youcanchangethescaleofthecurvetoîš¿tthevertical
spaceavailableontheechogram.ThescaleisprovidedintheEchogramdialog.
351718/C
121
