SimradEK15
SettingupexportofNMEAdatatochosenLANport
Purpose
ThisprocedureexplainshowtheEK15canbesetuptoexportallNMEAdataonan
Ethernetport.
Description
WhenNMEAdatafromtheEK15isexportedonaLANport,thenavigational
informationcanbereusedbyotherapplicationsrunningonthesamecomputer.
Relatedtopics
•I/OSetupdialogboxonpage194
•SelectOutputsdialogboxonpage231
Procedure
1ClicktheInstallationbuttontoopentheInstallationsub-menu.
Onthemenuprovided,clickI/OSetuptoopentheI/OSetupdialogbox.
2ClickonceonanexistingLANporttoselectit,thenclickOutput.
3IntheSelectOutputsdialogbox,clickReectorontheleftside,thenclick[>]to
moveittothelistofoutputs.
Nosetupisrequired.
4ClickOKtosavethecurrentsettingsandclosethedialogbox.
SettinguptheEthernetoutput
Purpose
ThisprocedureexplainshowtheEK15canbesetuptoexportdataonanEthernetport.
Description
ThroughEthernet,theEK15cancommunicatewithanperipheraldevicesthatcanbenet
fromtheprocesseddata.ThisEthernetcommunicationiscontrolledbytheEthernet
Outputdialogbox.Notethatthisinterfacewillrequiretheabsoluteidentityofthe
remoteUDPport
andtheremoteIPaddress .
Thefollowingtelegramsmaybeexported:
•Parameter
•Vessellog
•Navigation
•Motionsensor
•Depth
•Echogram
88
351718/C
