SimradEK15
•Recordbuttononpage108
•Informationpaneiconsonpage109
•NavigationFieldonpage110
•Functionbuttonsonpage112
StatusBar
TheStatusBarislocatedatthebottomoftheEK15presentation.
ThepurposeoftheStatusBaristogiveyoufastaccesstokeyfunctionality,aswellas
timeanddateinformation.
APresentationformat
•Vertical:Thistabplacesyourcurrentechogramsnexttoeachotherinavertical
presentation.
•Horizontal:Thistabplacesyourcurrentechogramsontopofeachotherina
horizontalpresentation.
•Square:Thistabplacesyourcurrentechogramsinarectangularpresentation.
Ifonlyoneactivefrequencychannelisinuse,youwillhaveonlyoneechogram.
Thesetabsarethennotshown.
BTransducerselection
ThesetabsontheStatusBarreecttheactualtransducersusedbytheEK15.The
twotransducersshownherearejustanexample.Ifonlyonetransducerisinuse,
youwillhaveonlyoneechogram.Thesetabsarethennotshown.
•ES10:ThistaballocatestheEK15presentationtoonlyshowtheechogramfrom
thistransducer.
•ES10(2):ThistaballocatestheEK15presentationtoonlyshowtheechogram
fromthistransducer.
CScreenCaptures
ThistabontheStatusBarhidesthecurrent“live”echogramsfromview,andallows
youtoseetheechogramimagesyouhavepreviouslysavedusingtheScreenCapture
buttonontheTitleBar.
Theechogramsarepresentedinagraphicbrowser.Youcanopenanyoftheimages
foracloserstudy,oryoucanaccessthelesdirectlybyclickingtheOpenImage
Folderbutton.
DColourscale
ThiscolourbarontheStatusBarpresentsthecurrentlyselectedcolourscale.
Whichcolourscaletouseismainlyapersonalpreferencebasedonambientlight
conditions,thenatureoftheechoesandyourownexperience.
38
351718/C
