Simrad EK15 User Manual

Functionsanddialogboxes
jGyro
Thisisinputfromaperipheralgyroorcompasssystemprovidingheading
information.Thefollowingtelegramformatsaresupported:
→HDGHeading,deviationandvariationonpage253
→HDTHeading,trueonpage254
→HDMHeading,magneticonpage254
→VHWWaterspeedandheadingonpage255
2SelectedInputs
Thiseldliststheselectedinputsignalsyouhavechosentoconnecttotherelevant
communicationport.
3CongureInput
Someoftheinputsmayneedtobecongured.Todothis,clickontheinputname
intheSelectedInputseld,andthenthisbutton.Whenapplicable,therelevant
setupdialogwillopen.
Relatedtopics
•Externalinterfaceproceduresonpage87
•Navigationdialogboxonpage176
•I/OSetupdialogboxonpage194
SelectOutputsdialogbox
TheSelectOutputsdialogboxisopenedfromtheOutputsbuttonintheI/OSetupdialog
box.
Purpose
TheSelectOutputsdialogboxallowsyoutoselectinformationtobeexportedto
peripheralsystemsonthechosenEthernet(LAN)orseriallineoutput.
Description
IntheSelectOutputsdialogbox,all
availableoutputsignalsarelistedinthe
lefttexteld.
Toenableanoutput,clickonitintheleft
columntoselectit,andthenclickthe[►]
button.
Iftheoutput'scommunicationparameters
canbesetup,clickthesignalnametoselectit,andthenclicktheCongureOutput
button.Ifapplicable,therelevantdialogwillopen.
351718/C
231
