Simrad EK15 User Manual

Operationalprocedures
Procedure
Thefollowingmethodsmaybeused.
1Method1
aClick[+]or[-]toadjustthestartrangemanually.
2Method2
aClickthemiddleofthebutton,holdthemousebuttondepressed,anddrag
sideways.
3Method3canonlybeusedifyouhaveakeyboard
aClickthemiddleofthebuttontoopenit.
bTypeanydepthvaluefromthekeyboard.
Choosingautomaticstartdepth
Purpose
Thisprocedureexplainshowtoenableuseofthe
automaticstartdepthfunction.Thestartrangeis
controlledbytheStartRangebuttonontheMainmenu.
Note
TheAutomaticStartDepthfunctionwillonlyworkinsurfacerelatedechograms.
Example5AutomaticStartDepth
IfyousetRangeto20metersandenabletheAutomaticStartDepthfeature,your
echogramwillalwaysbedrawntomakethebottomcontourappearclosetothe
bottomofyourechogrampresentation.Ifthewaterdepthexceeds20meters,the
EK15willautomaticallymovethestartrangedown.Therangeiskept,butasthe
startrangeismoved,thebottomcontourisstillvisible.
Relatedtopics
•StartRangefunctiononpage146
Procedure
1ObservetheMainmenu.ItisnormallylocatedontherighthandsideoftheEK15
presentation.
2ObservetheStartRangebutton.
3Clickthemiddleofthebuttontoopenit.
4ClicktoenableAutomaticStartDepth.
5Clickthemiddleofthebuttontocloseit.
351718/C
71
