Simrad EK15 User Manual

Functionsanddialogboxes
Installationmenu
TousetheInstallationfunctions,clickInstallationontheSetupmenu.
Purpose
TheInstallationfunctionopensasmallsubmenuwithaccesstothefunctionsanddialog
boxesrequiredtosetuptheEK15foroperationaluse.
1Environment
ThepurposeoftheEnvironmentdialogboxis
toadjusttheparametersrelatedtosalinity,sound
speedandwatertemperature.
→Environmentdialogboxonpage189
2RemoteControl
TheRemoteControldialogboxallowsyouto
controltheremotelycontrolledoperationofthe
EK15,bothhowtheEK15canbecontrolledfrom
aperipheralsystem,andhowtheEK15canexport
informationtothissystem.
→RemoteControldialogboxonpage191
3I/OSetup
TheI/OSetupdialogboxallowsyoutocontrolthepropertiesofeachoftheavailable
communicationchannelsontheEK15ProcessorUnit.
→I/OSetupdialogboxonpage194
4TransceiverInstallation
ThepurposeoftheTransceiverInstallationdialogboxistosetupthenecessary
parameterstoconnecttheEK15computertothetransceiver(s)andthetransducer(s).
→TransceiverInstallationdialogboxonpage199
Environmentdialogbox
TheEnvironmentdialogboxisopenedfromtheEnvironmentbuttonmadeavailable
whenyouclicktheInstallationbuttonontheSetupmenu.
Purpose
ThepurposeoftheEnvironmentdialogboxistoadjusttheparametersrelatedtosalinity,
soundspeedandwatertemperature.
351718/C
189
