Simrad EK15 User Manual

SimradEK15
Monitoringthecurrentbiomass
Purpose
ThisprocedureexplainshowtoopentheBiomassinformationpane.
Description
ThebiomassispresentedusingtheBiomassinformationpane,and/orenablingthe
Biomassline
Relatedtopics
•Biomassinformationpaneonpage125
•Echogrammarkersonpage120
•Transparencyfunctiononpage163
Procedure
1ClicktheBiomassicon.
ThisiconislocatedontheTitleBar.ItisusedtoopentheBiomass
informationpane.
2Tochangethesizeoftheinformationpane,clickinthebottomright
corner,holdthemousebuttondepressed,anddrag.
3Tochangethetransparencyoftheinformationpane,opentheDisplaymenu,and
clicktheTransparencybutton.
4Clickonthehistogramtitlestoseethepresentationsfromthedifferentechograms.
Enablingthebiomassline
Purpose
ThisprocedureexplainshowtoenabletheBiomassline.
Description
ThebiomassispresentedusingtheBiomassinformationpane,and/orenablingthe
Biomassline
Relatedtopics
•Biomassinformationpaneonpage125
•Echogrammarkersonpage120
•Activemenuonpage139
