Simrad EK15 User Manual

Themenusystem
5EthernetOutput
ThepurposeoftheEthernetOutputdialogboxistodenethecommunication
parametersfortheEK500datagramoutputontheEthernetport.
→EthernetOutputdialogboxonpage184
6DepthOutput
TheDepthOutputdialogboxisusedtosetuptheoutputofdepthdatafromthe
EK15toadedicatedcommunicationportonaspeciedformat.
→DepthOutputdialogboxonpage186
7Installation
TheInstallationfunctionopensasmallsubmenuwithaccesstothefunctionsand
dialogboxesrequiredtosetuptheEK15foroperationaluse.
→Installationmenuonpage189
Activemenu
TheActivemenuiscontextsensitive.Thismeansthatitisemptyuntilyou
clickinaviewontheEK15presentation.Thechosenviewwillappearwith
athickerframetoindicatethatitis“active”.TheActivemenuwillthen
offeraselectionoffunctionsrelativetotheactiveview.TheActivemenu
willthuschangefromdifferentviewsanddifferentpresentationformats
Whiletheillustrationshownhereonlyprovidesalimitedamountofchoices,thelist
holdsalltheoptions.
ClickonceontheiconundertheMainmenutoopentheActivemenu.Clickonemore
timeontheicontoclosethemenu.
1Echogram
TheEchogramdialogboxallowsyoutosetupthe
parameterscontrollingtheechogrampresentation.
Thethreetabscontrolthehorizontallines,the
echogramtypewithappliedTVG,andhowfast
theechogrammovesacrossthedisplay.
→Echogramdialogboxonpage206
2TVG
TheTVG(TimeV ariableGain)functionallows
youtocompensatethereceiveddataforlossdue
togeometricspread.
→TVGfunctiononpage215
351718/C
139
