SimradEK15
Poweron/offprocedures
TheseproceduresexplainhowtoswitchtheEK15systemonandoff.
Note
WhenyoupoweruptheEK15fortheveryrsttime,observetheproceduresinchapter
Installationonpage287.
Topics
•PoweringuptheEK15onpage44
•PoweringdowntheEK15onpage45
PoweringuptheEK15
Purpose
ThisprocedureexplainshowtopoweruptheSimradEK15system.
ThisprocedureassumesthatyouhaveconnectedoneormoretransceivertotheEK15.If
thisisnotthecase,observetherelevantstart-upprocedureinchapterInstallation.
Relatedtopics
•Settingoperationalmode'Normal'tostart'pinging'onpage24
•Startingnormaloperationonpage23
•Checkingthebottomdetectorsettingsonpage26
•SettinguptheEK15transceiver(s)forthersttimeonpage289
•Operationmenuonpage136
•UserSettingsdialogboxonpage142
•Pingfunctiononpage151
Procedure
1Verifythatthetransceiver(s)areswitchedon.
TheSingleBeamTransceiver(SBT)isnotprovidedwithanon/offswitch.
Unlessadedicatedsolutionhasbeenprovidedduringtheinstallationtofacilitate
poweron/off,thetransceiver(s)arepermanentlypoweredup.However,iftheEK15
hasnotbeenusedforalongerperiodoftime,thepowertothetransceiver(s)may
havebeendisconnected.
2Powerupthecolourdisplay.
Ifrequired,refertotheinstructionsprovidedbythedisplaymanufacturer.
3PoweruptheProcessorUnit(computer).
Waitfortheoperatingsystemtostartup.
4Double-clicktheEK15icononthedesktoptostarttheprogram.
5Waitwhiletheprogramstartsonthecomputer.
44
351718/C
