Simrad EK15 User Manual

Operationalprocedures
bIfyouwishtorunthereplaylecontinuously,clickLoopintheReplayFile
dialogbox.
cClickOKtosavethecurrentsettingsandclosethedialogbox.
5ClicktheOperationbuttontoopenthemenuchoices.
6ClickReplaytoselectthisfunction.
ObservethattheReplaybaropens.
7ClickthestartbuttonintheReplaybartostarttheplayback.
8Tostoptheplayback,youhavetwochoices:
aClickthestopbuttonintheReplaybar
bReturntonormaloperationalmodeusingtheOperationbutton.
Accessingthescreencaptureimagelestodelete,move
orcopy
Purpose
Oncethescreencapturebitmapimageshavebeensaved,youmayalsowishtodelete
them,orcopyormovethemfromthecomputer'sharddisktoaseparatestoragemedia.
Thisprocedureexplainshowtoaccesstheles,andhowtocopyormovethemtoa
separatestoragedevice.
Important
ThisprocedureassumesthatyouarefamiliarwiththeMicrosoft
®
XP
®
and/orMicrosoft
®
7operatingsystemutilitiesforlehandling.
Procedure
1ObservetheScreenCapturebuttonontheStatusBaratthebottomofthe
presentation.
2ClickScreenCaptures.
Observethatthebuilt-inimagebrowserstarts.Allthecurrentlysavedechogram
imagesareshownasminiatures.
3Inthebrowser,clickOpenImageFoldertoopenanoperatingsystemfolder.
4Usethefunctionalityprovidedbytheoperatingsystemtonavigatetothelefolder
withthebitmaples.
Thisisthedefaultdirectoryforthebitmapimages:
Windows7:c:\programdata\Simrad\EK15\ScreenDumps
→FileOutputdialogboxonpage236
5Prepareaseparatedatastoragedevice
ThisistypicallyalargecapacityUSBmemorydeviceoraharddisk.Youcanalso
connecttheEK15computertoanetwork,andcopythelestoaserver.
6Usethefunctionalityprovidedbytheoperatingsystemtodeletetheles,ortocopy
ormovethemtotheseparatestoragedevice.
351718/C
57
