Simrad EK15 User Manual

SimradEK15
Setupmenu;functionsanddialogs
ThefollowingfunctionsandparametersareavailablefromtheSetupmenu.
ClickonceontheiconundertheMainmenutoopentheSetupmenu.Clickonemore
timeontheicontoclosethemenu.
1Synchronization
ThepurposeoftheSynchronizationdialogboxisto
setuptheEK15tooperatealone,orasamasteror
slaveinasynchronizedsystem.Synchronizationis
requiredinordertoavoidinterferenceiftheEK15
isusedsimultaneouslywithotherhydroacoustic
instrumentswithinthesamefrequencyrange.
→Synchronizationdialogboxonpage171
2Annotations
ThepurposeoftheAnnotationsdialogboxisto
allowyoutoentercommentsandannotations
intotheechograms.
→Annotationsdialogboxonpage173
3CalculationInterval
TheCalculationIntervaldialogboxallowsyoutodenethetime,numberofpings,
orpartoftheechogramviewusedtocalculatethebiomassandthesizedistribution.
→CalculationIntervaldialogboxonpage174
4Navigation
TheNavigationdialogboxcontrolshowtheEK15receivesinformationfrom
externalperipherals,suchasnavigationandgyrocompasssystems.
→Navigationdialogboxonpage176
5EthernetOutput
ThepurposeoftheEthernetOutputdialogboxistodenethecommunication
parametersfortheEK500datagramoutputontheEthernetport.
→EthernetOutputdialogboxonpage184
6DepthOutput
TheDepthOutputdialogboxisusedtosetuptheoutputofdepthdatafromthe
EK15toadedicatedcommunicationportonaspeciedformat.
→DepthOutputdialogboxonpage186
7Installation
TheInstallationfunctionopensasmallsubmenuwithaccesstothefunctionsand
dialogboxesrequiredtosetuptheEK15foroperationaluse.
→Installationmenuonpage189
170
351718/C
