Operationfunction
TocontroltheOperation,clickOperationontheOperationmenu.
Purpose
ThepurposeoftheOperationfunctionistocontroltheoperationalmodeoftheEK15.
YoucansetittoNormal,ReplayorInactive.
Description
TheEK15willduringnormaloperationdisplaythe
echosignalreceivedatthetransducer.Usingthis
Operationfunction,itmayalsobesetuptoplayback
apreviouslyrecordedechosignal.
IfyoudonotwishtousetheEK15forashortperiod,
youcansetitsoperationalmodetoInactive.
Clickthemiddleofthebuttontoopenthesubmenu.
IfyouwishtorunthesysteminReplaymode,youwillalsoneedtoclicktheReplay
Filebuttontoselectreplayle.
Parameters
1Inactive
ClickthisoptiontodisabletheEK15operation.Neithertransmissionorreception
willtakeplace.
2Normal
Clickthisoptiontoenternormaloperationalmode.
Tip
Ifyouwishtoestablishapassivesystem(transmissionswitchedoff,butnormal
reception),clicktheNormalOperationbutton,andselectPassivemodeinthedialog
box.
3Replay
Clickthisoptiontochooseplaybackmode.
Inordertoselectwhichrecordedletoplayback,clicktheReplayFilebuttonto
opentheReplayFiledialogbox.
Torecorddata,usetheRecordfunctionontheOperationmenu.
150
351718/C
