6Communicationmode
ChooseBroadcastorPoint-to-Point.
BroadcastmodeenablesdatatobesentfromtheEK15toanynumberofremote
systems.Dataistherebyonlytransmittedtothesesystems.Theremotesystems
receivethedata,buttheEK15doesnotreceiveanyreplyoracknowledgement
fromthem.
Point-to-PointmodeimpliesthattheEK15isphysicallyconnectedonlytoone
singleremotesystem.Thevalueofsuchapermanentpoint-to-pointnetworkis
unimpededcommunicationsbetweenthetwoEK15andtheremotesystem.A
completetwo-waycommunicationsystemisthenused.
Relatedprocedures
•Externalinterfaceproceduresonpage87
Relatedtopics
•Setupmenu;functionsanddialogsonpage170
•EK500Datagramdialogboxonpage240
•I/OSetupdialogboxonpage194
DepthOutputdialogbox
TheDepthOutputdialogboxisopenedfromtheDepthOutputbuttonontheSetupmenu.
Purpose
TheDepthOutputdialogboxisusedtosetuptheoutputofdepthdatafromtheEK15to
adedicatedcommunicationportonaspeciedformat.
Description
Thisdialogboxallowsyoutodenewhichport(serialorEthernet)tousefordepth
output,andwhichformattouse.YoucansetuptheEK15toexportthedepthinformation
onmorethanoneport.
TheEK15mayoutputthecurrentdepthonseveralNMEAdatagramformats,aswellas
anumberofproprietaryformats.
Thefollowingdepthtelegramformatsaresupported:
186
