4Gain
ThepurposeoftheGainfunctionistoadjusttheecholevelintheechogram
presentations.
→Gainfunctiononpage147
Submenus
ThebottomoftheMainmenuholdstheiconsforthesubmenus.Clickononeofthese
iconstoopentherequestedsubmenu.
Menubutton
OntheTitlebar,clickonceontheMenubuttontohidethemenu.Click
onemoretimetobringthemenubackagain.
Operationmenu
ThefollowingfunctionsandparametersareavailablefromtheOperation
menu.
ClickonceontheiconundertheMainmenutoopentheOperationmenu.
Clickonemoretimeontheicontoclosethemenu.
1Operation
ThepurposeoftheOperationfunctionistocontrol
theoperationalmodeoftheEK15.Youcanset
ittoNormal,ReplayorInactive.
→Operationfunctiononpage150
2Ping
ThepurposeofthePingfunctionistoenableor
disabletheEK15audiotransmissionsintothe
water(“pinging”).
→Pingfunctiononpage151
3PingMode
ThePingModefunctionisusedtocontrolhow
oftentheEK15shalltransmititsenergyintothe
water.Fornormaluse,chooseMaximum.ThiswillallowtheEK15totransmit
continuouslyandasoftenaspossible.
→PingModefunctiononpage152
4PingInterval
UsethePingIntervalfunctiontochoosethetime(inmilliseconds)betweeneach
transmission(ping)whenPingModeissettoInterval.
→PingIntervalfunctiononpage153
