SimradEK15
5Delete
Thisbuttonisusedtodeleteoneofthesavedsettings.
Todeleteasetting,clickthesettingname,andthenthisbutton.Adedicateddialog
boxopenstoverifyyourchoice.
Thefactorysetting(s)cannotbedeleted.
6SaveCurrentSetting
ThisbuttonisusedtosavethecurrentlyappliedEK15settings.
Tosavethesettings,clickthisbutton.Adedicateddialogboxopenstorecordthe
nameofthenewsettings.
Tip
IfyoudonothaveacomputerkeyboardconnectedtoyourEK15system,clickthe
Keyboardbuttontoopenanon-screenkeyboard.
YoucanonlyaddsettingstotheSavedSettingslist.
Relatedprocedures
•ChoosingEK15factorydefaultsettingsonpage48
•Savingthecurrentusersettingsonpage47
•Usingpreviouslysavedsettingsonpage48
Relatedtopics
•Mainmenu;functionsanddialogsonpage142
Rangefunction
TochangetheRange,clickRangeontheMainmenu.
Purpose
TheRangefunctionallowsyoutospecifytheverticalrangeofthewatercolumncovered
bytheechogram.Therangeisdenedfromaselectedstartrange,anddowntoavalue
beneaththecurrentbottomdepth.Thevalueshownandselectedisbydefaultapplied
onlytothecurrentlyselectedechogram.
Description
Therangesettingdeneshow“deep”youwishthe
EK15todetectechoes,thatistheverticaldistance
betweenthe“top”andthe“bottom”oftheechogram.
TheRangesettingspeciesthis“bottom”depth,while
theStartRangesettingspeciesthe“top”depth.
Therangeyouspecifyappliestothecurrentlyselected
echogram(identiedwithathickborder).Severalechogramtypesareavailable,these
areselectedintheEchogramdialogbox.
144
351718/C
