Themenusystem
Aboutmenusandbuttons
TheselectionofoperationalparametersontheEK15isdoneusingatreestructurewitha
mainmenu,asetofsubmenus,andseveralmenubuttons.Someofthemenubuttons
opendialogboxesorsubmenustoofferadditionalchoices.
TheMainmenuprovidestheparametersmostfrequentlyusedduringnormaloperation.
Belowthemainmenu,dedicatedbuttonsareusedtoopenthesubmenus.Theseare
(fromleft):
ATheOperationmenucontrolsthemainoperationalparameters.
BTheDisplaymenucontrolsthevisualaspectsofthesystem,suchasparameters
relatedtothedisplaypresentation.
CTheSetupmenuallowsyoutocontrolthecongurationofthesignalprocessing,as
wellassysteminstallationandmaintenance,andtheinterfacestoperipheraldevices.
DTheActivemenuhasitscontentlinkedtothecurrentactiveitem(vieworobject).
Useittoaccessspecialfeaturesavailablefortheselectedvieworobject.
Tip
Youcanhidethemenufromviewifyoudonotneedit.ClicktheMenubutton
ontheTitleBartohidethemenu.Clickonemoretimetoretrieveit.
Thetextinthebuttonscanbechangedtosuityourpreferencebyclicking
LanguageontheDisplaymenu.
YoucanalsoplacethemenuontheleftsideoftheEK15presentationbyclickingMenu
ontherightsideintheDisplayOptionsdialogbox.
Menubutton
OntheTitlebar,clickonceontheMenubuttontohidethemenu.Click
onemoretimetobringthemenubackagain.
351718/C
133
