Simrad EK15 User Manual

Installation
Relatedtopics
•Setupmenuonpage138
•Checkingthetransceiverandtransducersettingsonpage25
•TransceiverInstallationdialogboxonpage199
Procedure
1ClicktheSetupicon.
ThisiconislocatedundertheMainmenu.ItisusedtoopentheSetupmenu.
2ClicktheInstallationbuttontoopentheInstallationmenu.
Onthemenu,clickTransceiverInstallationtoopentheTransceiverInstallation
dialogbox.
ThepurposeoftheTransceiverInstallationdialogboxistosetupthenecessary
parameterstoconnecttheEK15computertothetransceiver(s)andthetransducer(s).
3IntheTransceiverInstallationdialogbox,clickBrowse.
TheEK15willautomaticallysearchthenetworkfortransceivers.
4Observethatallthefrequencychannelsarelistedinthedialogbox.
5Selectafrequencychannelthatisavailable,andchoosethecorrecttransducerin
thespinbox.
Note
Thisisacriticaltask.Youmustensurethatthecorrecttransducerisselected.If
youconnectthetransceivertoatransducerthatcannothandlethepowerrating,it
maybedamagedbeyondrepair .
OntheEK15,choosetransducer200–28CMasdefault.Othertransducerscanalso
beused.
6ObservethatthestatusfortherelevantfrequencychannelschangestoInstalled.
7ClickOKtosavethecurrentsettingsandclosethedialogbox.
ChangingtheIPaddresseswhenmorethan
onetransceiverisused
Purpose
ThisprocedureexplainshowtomodifythisIPaddress.
351718/C
293
