Functionsanddialogboxes
Relatedprocedures
•Installingafrequencychannelonpage81
•Disconnectingafrequencychannelonpage82
•ModifyingatransceiverIPaddressonpage82
Relatedtopics
•Setupmenu;functionsanddialogsonpage170
•NormalOperationdialogboxonpage154
•Installationmenuonpage189
Activemenu;functionsanddialogs
TheActivemenuiscontextsensitive.Thismeansthatitisemptyuntilyou
clickinaviewontheEK15presentation.Thechosenviewwillappearwith
athickerframetoindicatethatitis“active”.TheActivemenuwillthen
offeraselectionoffunctionsrelativetotheactiveview.TheActivemenu
willthuschangefromdifferentviewsanddifferentpresentationformats
Whiletheillustrationshownhereonlyprovidesalimitedamountofchoices,thelist
holdsalltheoptions.
ClickonceontheiconundertheMainmenutoopentheActivemenu.Clickonemore
timeontheicontoclosethemenu.
1Echogram
TheEchogramdialogboxallowsyoutosetupthe
parameterscontrollingtheechogrampresentation.
Thethreetabscontrolthehorizontallines,the
echogramtypewithappliedTVG,andhowfast
theechogrammovesacrossthedisplay.
→Echogramdialogboxonpage206
2TVG
TheTVG(TimeV ariableGain)functionallows
youtocompensatethereceiveddataforlossdue
togeometricspread.
→TVGfunctiononpage215
3BeamDirection
ThepurposeoftheBeamDirectionfunctionistoturntheechogrampresentation
up-sidedown.ThisistypicallyusediftheEK15transducersarelocatedatthe
bottomofashcagelookingupwards.
→BeamDirectionfunctiononpage216
351718/C
205
