Relatedtopics
•Gainfunctiononpage147
Procedure
1ObservetheMainmenu.ItisnormallylocatedontherighthandsideoftheEK15
presentation.
2ObservetheGainbuttonontheMainmenu.
3Method1
aClick[+]or[-]tochoosegain.
4Method2
aClickthemiddleoftheGainbutton,holdthemousebuttondepressed.
bDragthecursorleftorrighttoincreaseordecreasethegain.
5Method3canonlybeusedifyouhaveakeyboard
aClickthemiddleoftheGainbuttontoopenthesubmenu.
bTypetherequestedgainvalue.
AdjustingtheTVGgainontheActivemenu
Purpose
ThisprocedureexplainshowtochangetheTimeVaried
Gain(TVG).
TheTVGcanbechosenusingtheEchogramdialog
box,orwiththeTVGbuttonontheActivemenu.This
secondmethodisdescribedinthisprocedure.
Description
TVGmeansTimeV ariedGain.
ThewholeideawithTVGisthatechoesfromshshallhavethesameecholevel(colour)
independentoftheirdepths.
TheEK15hasaTVGrangedownto15000meters,whichforallpracticalpurposesis
unlimited.TheEK15doesnothaveaTVGcompensatedreceiverlikemostotherecho
sounders.IntheEK15theTVGismadeinsoftwareaftertheechoesfromthereceiver(s)
havebeenconvertedtodigitalformat.Inordertomakethisworkthereceivermust
haveverylargedynamicrange.
ThefollowingTVGsettingsareavailable:
aPower(NoTVG)
TVGgainisnotimplemented.Thissettingishardlyeverused.
76
351718/C
