Simrad EK15 User Manual

SimradEK15
Procedure
1ClicktheActiveicon.
ThisiconislocatedundertheMainmenu.ItisusedtoopentheActive
menu.
2ClickEchogramtoopentheEchogramdialogbox.
TheEchogramdialogboxallowsyoutosetuptheparameterscontrollingthe
echogrampresentation.Thethreetabscontrolthehorizontallines,theechogram
typewithappliedTVG,andhowfasttheechogrammovesacrossthedisplay.
3OntheLinestab,observethevariousmarkersthatcanbeenabled.
4Enablethelinesyouwishtosee.
5ClickOKtosavethecurrentsettingsandclosethedialogbox.
Addingverticalmarkersandannotationstotheechogram
Purpose
Thisprocedureexplainshowyoucanenableoneormoreverticalmarkersinthecurrent
echogram.
Description
TheechogramsprovidedbytheEK15maybesetuptocontainadditionalinformation.
Thefollowinglines,markersandannotationscanbeenabled:
•Bottomlineonpage120
•Whitelineonpage120
•Variabledepthlineonpage121
•Rangeotherlinesonpage121
•Biomasslineonpage121
•Rangescalesonpage122
•Verticalticksonpage122
•Annotationsonpage123
Relatedtopics
•Activemenuonpage139
•Echogram;Linestabonpage208
•Annotationsdialogboxonpage173
66
351718/C

Simrad EK15 Specifications

General

Brand	Simrad
Model	EK15
Category	Marine Equipment
Language	English
