SimradEK15
Echogram;Linestab
Purpose
TheLinestabintheEchogram
dialogboxallowsyoutocontrol
thehorizontalandverticallines
usedtoenhancetheechogram
presentation.Itallowsyoutochange
theappearanceofthebottomline.
Youcanaddanextrabottomline,
andinadditiontothisyoucanenable
eitherawhitelineorahardness
indicatorline.Thetabalsooffers
severalhorizontalinformationlines,
andyoucanchoosetheverticalscale
oftheechogram.Finally,theLines
tabofferstimeordistancemarkers,
andyoucanenableannotations.
Important
Thechangesyoumakeherewillbydefaultonlybeappliedtothecurrentlyselected
“active”echogram(identiedwithathickborder).Ifyouwishtoapplythechangesto
alltheotherechogramsofthesametype(forexampleallbottomrelatedechograms),
clickApplyToAll.
Parameters
1HorizontalBottom
Thebottomlinecanbeswitchedofforon.Inaddition,youcanenableeitherwhite
lineorbottomhardnessinformation.
aOn/Off(Bottomlines)
Whenenabled,thedetectedbottomdepthisshownasathinlineinthe
echogram.Thelineisdrawninthecurrentforegroundcolour.
bNone
Neitherwhitelinenorhardnessinformationisshown.
cWhiteLine
Abandinthecurrentbackgroundcolourisdrawnbelowthedetectedbottom
depth.
dHardness
BottomhardnessisnotavailableontheEK15.
2HorizontalLines
Thiseldallowsyoutoenableordisableotherhorizontallinesontheechogram.
208
351718/C
