Simrad EK15 User Manual

SimradEK15
ScreenCapturebutton
TheScreenCapturebuttonislocatedontheleftsideoftheTitleBaratthe
topoftheEK15presentation.
Clickthisbuttononcetocreateascreencaptureofthecurrentechogram
presentation.Toviewtherecordedimage,clickScreenCaptureontheTaskBartoopen
theimagebrowser.
Relatedtopics
•Savingasingleechogramimageonpage53
•Recallingsingleechogramimagesonpage55
•Screencapturesonpage130
Recordbutton
TheRecordbuttonislocatedontheleftsideoftheTitleBaratthetopof
theEK15presentation.
Clickthisbuttontostartandstoprecording.
Remembertostoptherecordingwhenyouhavenishedthejob!Ifyouforget,your
harddiskmaybelled!
Note
Rawdataleswillnormallybecomeverylarge.Ifyouwishtorecordlargeamountsof
EK15rawdata,makesurethatyouhaveenoughspaceonyouharddisk.Unlessyour
computerisequippedwithaverylargediskcapacity,werecommendthatyousavethe
rawdatatoanexternalstoragedevice.
Relatedtopics
•Savingechogramsequences(rawdata)onpage54
•Recallingechogramsequences(rawdata)onpage56
•Recordfunctiononpage157
Eventbutton
TheEventbuttonislocatedontheleftsideoftheTitleBaratthetopofthe
EK15presentation.
TheEventbuttonisusedtoinitiateaneventannotationontheechogram.To
setupthetypeofevent,observetheparametersintheAnnotationdialogbox.
Relatedtopics
•Annotationsdialogboxonpage173
108
351718/C
