Simrad EK15 User Manual

SimradEK15
Selectingwhichechogramstodisplay
Purpose
YourEK15maybesetupwithoneormoretransceiversandtransducers(channels).
TheLayoutdialogboxallowsyoutocontrolwhichchannelsyoucanseeonthedisplay.
Relatedtopics
•Layoutdialogboxonpage164
Procedure
1ClicktheDisplaybuttontoopenthemenu.
ThisbuttonislocatedundertheMainmenu.Itisusedtoopenthe
Displaysubmenu.
2ClickLayouttoopentheLayoutdialogbox.
ThepurposeoftheLayoutdialogboxistodenewhichtransceiverchannelsyou
wishtopresentonthedisplaypresentation.Youcanalsopositiontheechogramsin
relationtoeachother.
3Makethenecessaryadjustments.
4ClickOKtosavethecurrentsettingsandclosethedialogbox.
Selectingcolourscaleandpresentationpalette
Purpose
Thisprocedureexplainshowtochangethecolourscaleandthepresentationpalette
ontheEK15echograms.
Description
Bydefaultyouhave64or12coloursavailabletopresenttheechograms,andaselection
ofpalettes.ThecolourscalecanberetrievedanytimebyclickingtheColourScale
iconontheTitleBar.
ThecurrentlyselectedcolourscaleisalsoshownontheStatusBar.
WhichcolourscaletouseisdenedintheColourSetupdialogboxontheDisplaymenu.
Relatedtopics
•ColourSetupdialogboxonpage160
60
351718/C
