Simrad EK15 User Manual

SimradEK15
Echogrammarkers
TheechogramsprovidedbytheEK15maycontainadditionalinformation.The
followinglines,markersandannotationscanbeenabled.
Topics
•Bottomlineonpage120
•Whitelineonpage120
•Variabledepthlineonpage121
•Rangeotherlinesonpage121
•Biomasslineonpage121
•Rangescalesonpage122
•Verticalticksonpage122
•Annotationsonpage123
Bottomline
ThislinemarkerisenabledintheEchogramdialog
boxontheActivemenu.
Thebottomcontourmaybeenhancedbyadding
abottomline.
Thebottomlineappearsasablackline,andfollowsthebottomcontour.
Relatedtopics
•Addinghorizontalmarkerstotheechogramonpage65
•Echogram;Linestabonpage208
Whiteline
ThislinemarkerisenabledintheEchogramdialog
boxontheActivemenu.
Thebottomcontourmayalsobeenhancedbyadding
awhiteline.
Thewhitelineisanextrathickwhitelinethatisaddedtojustbelowthebottom.The
whitelinewillnotremoveinformation,itwillsimply“push”theinformationfurther
downinordertomakethebottomeasiertosee.
Relatedtopics
•Addinghorizontalmarkerstotheechogramonpage65
•Echogram;Linestabonpage208
120
351718/C
