Displayviews
FFunctionbuttons
Thesebuttonsareusedtocontrolbasicsystemfunctions.
•Alarm:ClickthisbuttontoopentheMessagesdialogbox.Thisbuttonwillash
toindicatethatamessageisposted.
•Help:Clickthisbuttontoopenthecontextsensitiveon-linehelp.
•MinimizeandResize:ClickthesebuttonstoadjustthesizeoftheEK15
presentation.
•Exit:ClickthisbuttontoclosedowntheEK15application.
Relatedtopics
•Logoandproductnameonpage107
•Menubuttononpage107
•ScreenCapturebuttononpage108
•Recordbuttononpage108
•Eventbuttononpage108
•Informationpaneiconsonpage109
•NavigationFieldonpage110
•Functionbuttonsonpage112
Logoandproductname
TheLogoandProductnameislocatedonthe
leftsideoftheTitleBaratthetopoftheEK15
presentation.
TheSimradlogoandtheproductname(EK15)isshown.
Double-clicktheSimradlogotoreducethesizeoftheEK15presentation.Double-click
onemoretimetorestoretheoriginalsize.
Menubutton
TheMenubuttonislocatedontheleftsideoftheTitleBaratthetopofthe
EK15presentation.
ClickonceontheMenubuttontohidethemenu,andonemoretimetobringit
backagain.Whenthemenuishidden,itwilltemporarilybeshownontheleftorright
handsideofthedisplayifyoumovethecursortothatposition.
Relatedtopics
•Themenusystemonpage132
351718/C
107
