Simrad EK15 User Manual

Functionsanddialogboxes
Description
Tosupportprogramswhich
usedatafromtheSimrad
EK500echosounder,the
EK15canoutputasubset
oftheEK500dened
datagrams.Thisdialogbox
allowsyoutoenableor
disabletheEK500datagram
outputtotheEthernetport.
Thisoutputportisnot
managedbytheI/OSetup
dialogbox,buthandled
separatelyfromthisdialog
box.
Parameters
1OutputEK500
ClickthisboxtoenableordisabletheEK500datagramoutput.
Note
InordertodisableEK500datagramoutput,youmustalsoopentheEK500Datagram
dialogandclearalldataformatcheckboxes.
2EK500Datagram
ClickthebuttontoopentheEK500Datagramdialogbox.Inthisdialogbox,you
cansetuptheindividualdatagramstobeexported.
3LocalIPAddress
ThisistheInternetProtocol(IP)addressofthelocalEthernetinterfaceboard.
Inmostcases,eachEthernetboardhasauniqueIPaddress,evenwhenaninterface
boardsupportsmultiplesockets.Ifyouhavemorethanoneinterfaceboard,youare
providedwithalistoftheavailableaddresses.
4Remoteport(UDP)
Specifythelocalnetworkport.TheEK15usesthisnetworkporttotransmit
information.Theapplicationontheremotecomputerwill“listen”tothisport
number.
5RemoteIPAddress
SelecttheInternetProtocol(IP)addressfortheremotecomputer.
Ifthedatacommunicationissetuptoreceivedataonly,thisparameteris
notrequired.Ifyouwishtosetupanoutputforbroadcast,deneIPaddress
255.255.255.255.Thisisthedefaultsetting.
Ifyouusepoint-to-pointcommunicationinaclosednetwork,youneedtoenter
theremoteIPaddressmanually.
351718/C
185
