SimradEK15
gPSIMDHB
ThisproprietarySimradtelegramcontainsbiomassandbottomhardness.
→PSIMDHBBottomhardnessandbiomassonpage263
4TalkerID
IfyouwishtospecifyadedicatedTalkerIDonthetelegramformat,itcanbe
selectedhere.
TheTalkerIDisthersttwocharactersintheNMEAsentence.SelectNoneto
acceptalltalkeridentiers.
Tip
IfyoudonothaveacomputerkeyboardconnectedtoyourEK15system,clickthe
Keyboardbuttontoopenanon-screenkeyboard.
5Channel
Thiscolumnspecieswhichtransceiveryouareusingassourceforthedepth
information.Thetextstringprovidesthefollowinginformation:
•TransceiverID
•Transceiver'sIPaddress
•Transducername
Ifyouhavemorethanonetransceiver,youcanchoosewhichonetouse.
6Add
ClickthisbuttontoaddanewserialorEthernetportfordepthdataexport.You
canexportthedepthinformationonseveraldifferentportssimultaneouslyusing
differentdatagramformatsoneachoutputport.
7Remove
ClickthisbuttontoremovethecurrentlyselectedserialorEthernetdepthoutput
port.
Relatedprocedures
•Externalinterfaceproceduresonpage87
Relatedtopics
•Setupmenu;functionsanddialogsonpage170
•LANPortSetupdialogboxonpage222
•SerialPortSetupdialogboxonpage226
•Telegramformatsonpage247
•AbouttheNMEAtelegramformatonpage248
188
351718/C
