Sinee EM500 - Page 136

EM500 Open-Loop Vector Control Inverter User Manual
136
F18.11
Simple PLC
Running Stage
1 - 15
xxx
×
F18.12
PLC Running Time
of Present Stage
0.0 - 6000.0
xxx
×
F18.13
Not Used
F18.14
Load Speed
0 - 65535
rpm
xxx
×
F18.15
UP/DOWN Offset
Frequency
0.00 - 2*Maximum Frequency F00.16
Hz
xxx
×
F18.16
PID Setting
0.0 – PID Maximum Range
xxx
×
F18.17
PID Feedback
0.0 – PID Maximum Range
xxx
×
F18.18
Kilowatt-Hour
Meter, MWh
0 - 65535
MW
h
xxx
×
F18.19
Kilowatt-Hour
Meter,
K
Wh
0.0 - 999.9
kWh
xxx
×
F18.20
Output Power
0.00 - 650.00
kW
xxx
×
F18.21
Output Power
Factor
-1.000 - 1.000
xxx
×
F18.22
Numeric Input
Terminal Status 1
X5
X4
X3
X2
X1
xxx
×
0/1
0/1
0/1
0/1
0/1
F18.23
Numeric Input
Terminal Status 2
AI3
AI2
AI1
X7
X6
xxx
×
0/1
0/1
0/1
0/1
0/1
F18.24
Numeric Input
Terminal Status 3
AI4
X11
X10
X9
X8
xxx
×
0/1
0/1
0/1
0/1
0/1
F18.25
Output Terminal
Status
Y3
R2
R1
Y2
Y1
xxx
×
0/1
0/1
0/1
0/1
0/1
F18.26
AI1
0.0 - 100.0
%
xxx
×
F18.27
AI2
0.0 - 100.0
%
xxx
×
F18.28
AI3
0.0 - 100.0
%
xxx
×
F18.29
AI4
-100.0 - 100.0
%
xxx
×
F18.30
Communication
Setting
-100.0 - 100.0
%
xxx
×
F18.31
High-Frequency
Pulse Input
0.00 - 100.00
kHz
xxx
×
