EM500 Open-Loop Vector Control Inverter User Manual

138

: Inverter Overload

: Inverter Overheating Protection

E11

: Parameter Setting Conflict

E12

: Motor Overheating

E13

: Motor Overload

E14

: External Fault

E15

: Inverter EEPROM Fault

E16

: Communication Abnormality

E17

: Temperature Sensor Abnormality

E18

: Soft Start Relay Off

E19

: Current Detection Circuit

Abnormality

E20

: Stall Fault

E21

: PID Feedback Disconnection

E22

: Not Used

E23

: Keypad EEPROM Fault

E24

: Parameter Autotuning

Abnormality

E25

: Not Used

E26

: Offload Protection

E27

: Accumulated Power-On Time

Reach

E28

: Accumulated Running time Reach

E29

: Internal Communication Fault

E30

E32

: Not Used

E33

: CANopen Communication

Overtime

E34

: DeviceNET without Network

Power Supply

E35

: DeviceNET BUS-OFF

E36

: DeviceNET MACID Detection

Failure

E37

: DeviceNET IO Communication

Overtime

E38

: DeviceNET IO Mapping Error

E39

: Profibus-DP Parameterization

Data Error
