EM500 Open-Loop Vector Control Inverter User Manual
151
protection
Third place: Pressure feedback
disconnection protection
Fourth place: Temperature overrun
protection
Fifth place: Temperature feedback
disconnection protection
Sixth place: Not Used
Seventh place: The motor feedback
disconnection protection
Eighth place: Not Used
From right to left (0- No shield
1-shield )
F28.56
~
F28.65
Not Used
F28.66
JZ Multi-function
set
See the output terminals function table
49
〇
F28.67
BJ Multi-function
set
See the output terminals function table
7
〇
F28.68
Interface card
Positive and
negative logic
setting
0: JT Normally closed
1: JT Normally open
0
〇
F28.69
Sensor offset curve
setting
Ones Place: Interface board oil
temperature
0: Curve 1
1: Curve 2
2: Curve 3
3: Curve 4
Tens Place: Interface board Motor
temperature
0: Curve 1
1: Curve 2
2: Curve 3
3: Curve 4
hundreds place: Interface board
pressure
0: Curve 1
1: Curve 2
2: Curve 3
120
〇
