EM500 Open-Loop Vector Control Inverter User Manual
166
number. For example, the arithmetic result of 20.00 Hz (forward) and -40.00 Hz (reverse)
is -40.00Hz (reverse).
No.
Function
Range
Unit
Default
Type
F00.09
Reference Option
for Auxiliary
Frequency Source
B at Main and
Auxiliary
Arithmetic
0: Relative to Maximum
Frequency
1: Relative to Main
Frequency Source A
0
〇
At main and auxiliary arithmetic, the range of auxiliary frequency source B follows
the object option, and the default is the maximum frequency. If the selection corresponds
to main frequency source A (F00.09=1), auxiliary frequency source B changes along with
main frequency source A (the default is to follow the maximum frequency).
No.
Function
Range
Unit
Default
Type
F00.10
Main Frequency
Source Gain
0.0 - 300.0
%
100.0
●
F00.11
Auxiliary Frequency
Source Gain
0.0 - 300.0
%
100.0
●
F00.12
Synthetic Gain of
Main and Auxiliary
Frequency
0.0 - 300.0
%
100.0
●
F00.13
Analog Input
Adjustment of
Synthetic Frequency
0: Synthetic Frequency of
Main and Auxiliary
Channels
1: AI1* Synthetic
Frequency of Main and
Auxiliary Channels
2: AI2* Synthetic
Frequency of Main and
Auxiliary Channels
3: AI3 * Synthetic
Frequency of Main and
Auxiliary Channels
4: AI4 * Synthetic
Frequency of Main and
0
〇
