EM500 Open-Loop Vector Control Inverter User Manual
175
F01.02
Motor Rated
Voltage
50 - 2000
V
Up To
Specific
Model
〇
F01.03
Motor Rated
Current
0.01 - 600.00 (Motor Rated Power ≤
75kW)
0.1 - 6000.0 (Motor Rated
Power >75kW)
A
Up To
Specific
Model
〇
F01.04
Motor Rated
Frequency
0.01 - 600.00
Hz
Up To
Specific
Model
〇
F01.05
Motor Rated
Speed
1 - 60000
rpm
Up To
Specific
Model
〇
F01.06
Motor Winding
Connection
0: Y
1: Δ
Up To
Specific
Model
〇
F01.07
Motor Rated
Power Factor
0.600 - 1.000
Up To
Specific
Model
〇
F01.08
Motor
Efficiency
30.0 - 100.0
%
Up To
Specific
Model
〇
Function codes mentioned above are nameplate parameters of induction motor. For
the first time when inverter is wired to motor, please set the parameters above as per
motor nameplate before inverter running, regardless of the control mode, VF control
mode or vector control mode.
When motor rated power (F01.01) is set, inverter will modify the values of the
parameters of F01.03 - F01.08 automatically. Please pay attention while using inverter.
No.
Function
Range
Unit
Default
Type
F01.09
Stator Resistor
of Induction
Motor
1 - 60000 (Motor Rated Power ≤ 75kW)
0.1 -6000.0 (Motor Rated
Power >75kW)
mΩ
Up To
Specific
Model
〇
F01.10
Stator Resistor
of Induction
Motor
1 - 60000 (Motor Rated Power ≤ 75kW)
0.1 - 6000.0 (Motor Rated
Power >75kW)
mΩ
Up To
Specific
Model
〇
F01.11
Leakage
Inductance of
0.01 - 600.00 (Motor Rated Power ≤
75kW)
mH
Up To
Specific
〇
