Table 2-2 Overall and Installation Dimensions of EM500 Inverter
Model No.
W
W1/W2
H
H1
H2
D
D1
D2
d
Frame
EM500-0R7G/1R5P-1B/
2B/3B
130
115
/
120
228
220
219
153
108
75
5
(b)
EM500-1R5G/2R2P-1B/
2B/3B
EM500-2R2G/3R0P-1B/
2B/3B
EM500-4R0G/5R5P-3B
EM500-5R5G/7R5P-3B
140
130
270
261
258
172
128
94
5
EM500-7R5G/9R0P-3B
EM500-011G/015P-3B
180
150
368
353
343
210
165
136
7
EM500-015G/018P-3B
EM500-018G/022P-3B
EM500-022G/030P-3/3B
250
200
484
470
440
222
150
--
6.5
(c)
EM500-030G/037P-3/3B
EM500-037G/045P-3/3B
EM500-045G/055P-3/3B
315
220
560
546
513
250
180
--
7
EM500-055G/075P-3/3B
350
250
662
638
603
262
188
--
12
EM500-075G/905P-3/3B
EM500-090G/110P-3
386
300
753
724
700
292
231
300
13
(d)
EM500-110G/132P-3
416
300
855
825
793
307
246
315
13
EM500-132G/160P-3
EM500-160G/185P-3
497
397
1107
1076
1036
340
285
348
13
EM500-185G/200P-3
EM500-200G/220P-3
EM500-220G/250P-3
656
450
1348
1314
1261
388
232
395
13
EM500-250G/280P-3
EM500-280G/315P-3
EM500-315G/355P-3
801
680
1417
1383
1330
388
190
395
13
EM500-355G/400P-3
EM500-400G/450P-3
EM500-450G/500P-3
1000
920
1800
1645
--
600
520
450
17
(e)
EM500-500G/560P-3
EM500-560G/630P-3
