EM500 Open-Loop Vector Control Inverter User Manual
335
F15.30
Energy
Consumption
Brake
1: Enabled
1: Enabled
1: Enabled
1: Enabled
PID Parameters
F09.01
Numeric PID
Setting
5.0
5.0
5.0
F09.02
PID
Feedback
Source
2
：
AI2
2
：
AI2
2
：
AI2
F09.03
PID Setting
Feedback
Range
10.0
10.0
10.0
F09.05
Proportional
Gain 1
0.06
0.30
0.03
F09.06
Integral Time
1
0.000s
0.000s
4.000s
F09.07
Differential
Time 1
30.000ms
30.000ms
30.000ms
F09.08
Proportional
Gain 2
0.10
0.40
0.07
F09.09
Integral Time
2
0.000s
0.000s
4.000s
F09.10
Differential
Time 2
30.000ms
30.000ms
50.000ms
F09.11
PID
Parameter
Switching
2:
Automatic
Switching
by Offset
2:
Automatic
Switching
by Offset
2:
Automatic
Switching
by Offset
F09.12
PID
Parameter
Switching
Offset 1
5.00%
0.00%
5.00%
F09.13
PID
Parameter
Switching
Offset 2
45.00%
100.00%
45.00%
F09.16
Upper Limit
of PID
40.0%
