Sinee EM500 - Page 348

To Next Page

To Previous Page

EM500 Open-Loop Vector Control Inverter User Manual

348

F02.03

79: Remote Start

F02.04

23: External Fault Input

F02.05

9: Coast to Stop

F02.37

Minimum Input of Curve 2

2.20V

F03.00

49: Inlet Valve Control

F03.02

50: Fan Start-stop Control

Signals

F03.03

1:Inverter Running (RUN)

F03.21

38: The Fan Speed Output

F06.29

Injection Current at Low

Frequency Range

40.0%

Compressor driven by 2 inverters application
