EM500 Open-Loop Vector Control Inverter User Manual
353
unloading when greater than the upper limit pressure value, loading when smaller than
the lower limit pressure value.
No.
Function
Range
Unit
Default
Type
F28.22
Pressure limit
deviation
0.00~100.00
%
0.00
●
When the absolute value of error is less than this range, the PID function stops. When the
feedback reaches at the given value for the first time, the limit deviation starts to act, PID
function stops, when beyond the range, the limit deviation fails and the PID restarts to
work.
No.
Function
Range
Unit
Default
Type
F28.23
Pressure
disconnection
detection threshold
0.00~ Maximum pressure range
MPa
0.08
〇
F28.24
Pressure
disconnection
detection Time
0.0~6000.0, 0.0 :The Function is
Disabled
s
0.0
●
Disconnection detection value, when the feedback pressure is less than the set value of
this function code, the program will start counting, until the time of F28.24 is up, will the
system report E46 fault
No.
Function
Range
Unit
Default
Type
F28.25
sensor selection
Ones Place:oil temperature sensor
0: General channel
1: Interface card
Tens Place: motor sensor
0: General channel
1: PT100
2: KTY84-130/150
3: PTC130/150
hundreds place: Air pressure
sensor
0: General channel
1: Interface card
101
〇
Through this function code, you can select oil temperature, motor temperature (supports a
variety of sensors) and air pressure sensor. If an interface card is used, temperature sensor
can be adopted with PT100 .
