EM500 Open-Loop Vector Control Inverter User Manual
355
F28.35
Temperature
Regulation Upper
Limit
0.00~100.00
%
100.00
●
F28.36
Temperature
regulation
Lower Limit
0.00~100.00
%
100.00
●
PID control parameters are adjusted as per actual applications.
F28.35 / F28.36 are to control the upper limit and lower limit of temperature PID output
respectively.
No.
Function
Range
Unit
Default
Type
F28.37
Fan stop
temperature
0.00~ Maximum temperature
range
℃
70.0
●
F28.38
Stopping
temperature
running time
10~7200
s
1200
●
F28.39
Fan start delay
time
1~300
s
10
●
When the feedback temperature is higher than the set temperature of F28.28 upon the se
time of F28.39, the fan will start operation, namely fan start, output terminal function
code is valid.
When the feedback temperature is lower than the set temperature of F28.37 upon the set
time of F28.38, the fan will stop, the output terminal function code 50 is valid.
No.
Function
Range
Unit
Default
Type
F28.40
Temperature limit
deviation
0.00~100.00
%
0.00
●
When the absolute value of error is less than this range, the PID function stops. When the
feedback reaches at the set value for the first time, the limit deviation starts to act, PID
function stops, when it is beyond the range, the limit deviation fails and PID restarts.
No.
Function
Range
Unit
Default
Type
F28.41
Temperature
disconnection
detection threshold
0.0~ Maximum temperature range
℃
8.0
〇
F28.42
Temperature
disconnection
detection Time
0.0~6000.0, 0.0 :The Function is
Disabled
s
0.0
●
Disconnection detection value, when the feedback pressure is less than the set value of
