EM500 Open-Loop Vector Control Inverter User Manual
435
Register Values Lo
00
3)
change the operating frequency (such as 50.00Hz / 1388H)
Identifiers
Control
Field
Date Field
Send
0x401
04
00 07
13 88
Response
0x47F
02
01 00
Response
(abnormal）
0x4FF
02
01 04
Illustrate:
Send
Response
Abnormal Response
CAN-ID
0x401
CAN-ID
0x47F
CAN-ID
0x4FF
Date Length
04
Date Length
02
Date Length
02
Register address Hi
00
Slave Address
01
Slave Address
01
Register address
Lo
07
Abnormal code
00
Abnormal code
04
Register Values Hi
13
Register Values Lo
88
4)
Read the motor operating data (read F18.00, F18.06, F18.08 function code)
Identifiers
Control
Field
Date Field
Send
0x201
06
1200
1206
1208
Response
0x27F
08
01 00
13 88
00 E6
02 1C
Response
(abnormal）
0x2FF
02
01 04
Illustrate:
Send
Response
Abnormal Response
CAN-ID
0x201
CAN-ID
0x47F
CAN-ID
0x4FF
