EM500 Open-Loop Vector Control Inverter User Manual
445
MOD
Profibus-DP Expansion
Card and Inverter
Communication
Indicator
“Normally on” status means that DP expansion
card and inverter communicate with each other
normally. “Off” status means that DP expansion
card and inverter fail to communicate with each
other.
PRO
Profibus-DP Expansion
Card and Profibus Bus
Connection Indicator
“Normally on” status means that DP expansion
card and bus communicate with each other
normally. “Off” status means that DP expansion
card and bus fail to communicate with each other.
Table 6 DIP Switch of
Profibus-DP Expansion Card
Switch
Function
Choose terminal resistor
