EM500 Open-Loop Vector Control Inverter User Manual
86
AI2
54: Switch Main Frequency Source to
AI3
55: Switch Main Frequency Source to
High-Frequency Pulse Input
56: Switch Main Frequency Source to
Communication Setting
57: Inverter Enabled
58-78: Not Used
79: Remote Start
80: Power Frequency Conversion
81-88: Not Used
89: Feedforward Reset
90-103: Not Used
104: Inlet Pool Upper Limit Water
Level Signal
105: Inlet Pool Lower Limit Water
Level Signal
106: Inlet Pool Lack Of Water Level
Signal
107: Sewage Pool Upper Limit Water
Level Signal
108: Sewage Pool Lower Limit Water
Level Signal
109: Not Used
110: External Overpressure Signal
111: Not Used
112: Switch The Pump
113~120: Not Used
121: External Signals Of Material
supply disruptions
122: Winding traverse Detection Signal
123: Braking Reset Terminals
F02.15
Positive/Negative
Logic 1 of Numeric
Input Terminal
D7
D6
D5
D4
D3
D2
D1
D0
*00
00000
〇
*
X7
X6
X5
X4
X3
X2
X1
0: Positive Logic, Enabled at
On/Disabled at Off
1: Negative Logic, Disabled at
On/Enabled at Off
F02.16
Positive/Negative
Logic 2 of Numeric
D7
D6
D5
D4
D3
D2
D1
D0
000
00000
〇
X11
X10
X9
X8
AI4
AI3
AI2
AI1
