EM500 Open-Loop Vector Control Inverter User Manual
88
F02.31
Analog Input
Function
Ones Place: AI1
0: Analog Input
1: Numeric Input (0 for less than 1V, 1
for over 3V, contrary to the last time for
1V-3V)
Tens Place: AI2
0: Analog Input
1: Numeric input (the same as above)
Hundreds Place: AI3
0: Analog Input
1: Numeric input (the same as above)
Thousands Place: AI4 (Expansion
Card)
0: Analog Input
1: Numeric input (the same as above)
0000D
〇
F02.32
Analog Input Curve
Options
Ones Place: AI1 Curve
0: Curve 1
1: Curve 2
2: Curve 3
3: Curve 4
Tens Place: AI2 Curve
0: Curve 1
1: Curve 2
2: Curve 3
3: Curve 4
Hundreds Place: AI3 Curve
0: Curve 1
1: Curve 2
2: Curve 3
3: Curve 4
Thousands Place: AI4 Curve
0: Curve 1
1: Curve 2
2: Curve 3
3: Curve 4
3210D
〇
F02.33
Minimum Input of
Curve 1
0.00 - F02.35
V
0.10
●
F02.34
Setting
Corresponding to
Minimum Input of
Curve 1
–100.0 - +100.0
%
0.0
●
