Studer OnAir 3000 User Manual

OnAir Digital Mixing Consoles
6-78 Conguration
Document generated: 10.10.14
SW V6.0
Defined by Triggered Edge and Action Settings (Toggle)
In contrast to the GPInput Functions specified in ‘Defined by Triggered Edge
and Action Settings (InputLevel)’ below, these functions toggle the specified
DNet parameters in cases where Triggered Edge is not BOTH and Action is
ALTERNATE.
GPI Function Arguments Description
ExtON
1: Logical Input / Strip Channel / AUX / N–X Parallel to the ON key in the channel strip
UserLED
1: User LED device ID (‘function’)
Sets the specified User LED parameter according to the GP
input signal.
This function connects the signal of a GP input pin to a User LED
Parameter. If the LED of a user key on the desk (e.g. Fader Assign
Module) is assigned to that parameter, the input can provide a
status feedback to the LED of a user key (also refer to the ‘UserKey’
GPO function).
ExternOnAir
– ON AIR LED activation (configured in ‘Signaling Settings’)
Outgate
1: GP Output Pin
Output x is only active if the Out function is active and the
Gate input is active
PFL
1: Logical Input / Strip Channel / Master /
/ Ext PFL
2: PFL CR / PFL Studio
PFL control signal from the CAB system is active
Ready
1: Logical Input External source is ready for playback
* ManualDucking
1: SubGroup1...8 External control of manual ducking
EnableOutput
Routing
1: Desk Group 1...8 Sets the enable parameter of the corresponding DeskGroup
ChannelUserLED
1: Logical Input / Master
2: User Function 1 / User Function 2
Sets the specified User LED Parameter according to the GP
Input signal.
This function connects the signal of a GP input pin to the specified
Channel User LED parameter of the specified channel. If the LED
of a user key on the desk (e.g. Fader Module) is assigned to that
parameter, the GPI can provide a status feedback to the LED of a
channel user key (also refer to the ‘ChannelUserKey’ GPO function).
UserKey
1: User Function External control of the User Key status
ChannelUserKey
1: Logical Input / Master External control of the Channel User Key status
* OnAir 3000 only
Defined by Triggered Edge and Action Settings (InputLevel)
In contrast to the GPInput Functions specified in ‘Defined by Triggered Edge
and Action Settings (Toggle)’ above, these functions set the specified DNet
parameters according to the InputLevel given by the Input Logic in cases
where Triggered Edge is not BOTH and Action is ALTERNATE.
GPI Function Arguments Description
LinkInput
1: GP Input Pin
Links the GP input to an existing GP input function (e.g. when
two keys shall be used for an On/Off function).
Tree Parameter: GPIOFunctions - GPInputFunctions -
GPInputFunctionX - FInputLogic - InputLevel.
If Triggered Edge of the corresponding GPInput Pin equals ‘both’,
InputLevel is set according to InputLevel (momentary).
Otherwise, if Action is either ACTIVATE or DEACTIVATE, InputLevel
is set according to Action.
Otherwise, InputLevel is set to InputLevel.
In a case where two GP Inputs are linked, the Action of the GP Input
Functions should be configured in such a way that one function
activates the InputLevel and the other deactivates it.
