Studer OnAir 3000 User Manual

OnAir Digital Mixing Consoles
Conguration 6-79
Document generated: 10.10.14
SW V6.0
Momentary and Latching User Requests
UserKey and User ON/OFF Requests.
GPI Function Arguments Description
Cough
1: Logical Input
Cough key, for mic and line inputs; input is muted, but no
change in signaling. Controls all logical inputs using the
same physical mic input; ‘time’ must not be set to >0
LS_CUT
1: CR / *ST1 / ST2 / *ST3 / CompactMonTBs
2: User / Machine
Monitor speakers CUT
LS_DIM
1: CR / *ST1 / ST2 / *ST3
2: User / Machine
Monitor speakers DIM
TalkBack
1: TB Source: CR / *ST1 / ST2 / *ST3 / Ext.
2: Destination: All TB destinations
Talkback from Source to Destination (Source = Destination
not allowed for SW up to V3.1)
EnableTalkback
1: Destination: All TB destinations Enables specified talkback destination
* OnAir 3000 only
Event-Driven Actions
The following GPInput functions are activated if the Input Logic sets the
InputLevel.
GPI Function Arguments Description
CR Source Selector
1: Monitor sources, Follow *ST1/ST2/*ST3 CR monitor source selector
* ST1 Source Selector
1: Monitor sources, Follow CR/ST2/ST3 Studio 1 monitor source selector
ST2 Source Selector
1: Monitor sources, Follow CR/*ST1/*ST3 Studio 2 monitor source selector
* ST3 Source Selector
1: Monitor sources, Follow CR/ST1/ST2 Studio 3 monitor source selector
CompMonTB Source
Selector
1: Compact Monitor/TB unit
2: Monitor sources, Follow CR/*ST1/ST2/*ST3
Compact monitor/TB unit monitor source selector
Cue Source Selector
1: Cue CR / *Cue ST1
2: Monitor sources, Follow CR/*ST1/ST2/*ST3
Cue monitor source selector
Snapshot
1: Primary Desk/*Secondary Desk/Not Spec.
2: All/CR/*ST1/ST2/*ST3
3: string
Recall the global snapshot with the name specified by ‘String’
for the given location
Next In
1: StartNextA/B_Request Start key
MicGroupKey
1: MicGroup1...12
Mic Group On Request key according to specified ext. Mic
Box key is on
FadeIn
1: Logical Input / Master
Starts the fade-in ramp of the specified LogicalInput or of the
LogicalInput of the specified StripChannel, respectively.
FadeOut
1: Logical Input / Master
Starts the fade-out ramp of the specified LogicalInput or of
the LogicalInput of the specified StripChannel, respectively.
OutputRoutingIn
1: Partial Output Routing 1...24 /
2: Ignore Enable Key / Desk Group1...8
Recall of Output Routing Snapshot with the name specified
by ‘String’.
Argument 2 is either undefined (for downward compatibility), Ignor-
eEnableKey, or a valid desk group 1...8.
All partial output routings with the option UseEnableKey set to ‘true’
need Argument 2.
If Argument 2 is IgnoreEnableKey partial output routings are loaded
unconditionally.
If Argument 2 is DeskGroup1...8, partial output routings check on
loading the enable status of the corresponding desk group.
If Argument 2 is not defined, the snapshot is not loaded!
Partial output routings with the option UseEnableKey set to ‘false’
are loaded unconditionally and do not need Argument 2.
* LSP Mode On
Red Light
1: CR / *ST1 / ST2 / *ST3
2: Dim / Cut / Nothing / CutAllowTB
Set loudspeaker dim/cut mode if ‘Red Light’ is ON
ResetChannel
1: Reset All / DeEs / EQ / Dynamics
2: Logical Input / Strip Channel / SubGroup
Reset Deesser/EQ/Dynamics or all parameters of the selected
channel or group
* OnAir 3000 only
