OnAir Digital Mixing Consoles
6-82  Conguration
Document generated: 10.10.14
SW V6.0
GPO Function Arguments Description
CueSourceSelector
1: Cue CR / *Cue ST1
2: MonitorCueKey
Active if the selected cue source is on
LinkOutput
GP Output pin Links the GP output to another GPO function
FaderstartWithPFL
1: Logical Input Fader start with ON key and fader, or PFL
FaderstartWithoutPFL
1: Logical Input Fader start with ON key and fader
TransparentOut
1: Device ID
Active if the value of the specified parameter is different from
zero (this function is normally used for factory testing only).
Only 64-bit device ID numbers in hex format are accepted as argu-
ment 1 – i.e., 0x followed by 16 digits (e.g. 0x1122334455667788)
RedLight_ONAIR
- Active if the ON AIR LED is on
* RedLight_ST1
- Active if Studio 1 red light indication is on
RedLight_ST2
- Active if Studio 2 red light indication is on
* RedLight_ST3
- Active if Studio 3 red light indication is on
RedLight_CR
- Active if Control Room red light indication is on
RedLight_PGMA
- Active if PGM A is on air
* RedLight_PGMB
- Active if PGM B is on air
RedLight_REC
- Active if REC is on air
* RedLight_5.1A
- Active if 5.1 A is On Air
* RedLight_5.1B
- Active if 5.1 B is On Air
MicMuteActive
1: Logical Input Active if mic is muted
ON
1: Logical Input / Strip Channel / AUX / N–X Active if ON key is on
UserKey
1: Device ID of a user key parameter Active if the value of the specified user key parameter is true
TB
1: TB Sources: CR / *ST1 / ST2 / *ST3 /
/ External
2: TB Destinations: All TB destinations
Active if the specified Talkback from Source to Destination is
active (since SW V3.2, also Source = Destination is allowed)
EnableTB
1: Destination: All TB destinations Active if the specified talkback destination is enabled
Locate
1: Logical Input Active if LOC/READY key of the logical input is on
OnMaster
1: Logical Input Active if channel on master is active
Next_Out
1: StartNextA/B_State Flashing if status = Ready, continuous if status = Next
RedLight_Input
1: Logical Input Active if specified strip channel is ON
MicGroupActive
1: MicGroup Active if ext. mic group key is Active or On Air
MicGroupReady
1: MicGroup Active if ext. mic group key is Ready
MicGroupOnAir
1: MicGroup Active if ext. mic group key is On Air
Setup
1: Setup1 | Setup 2 Active if the specified setup is active
LastSnapshot
1: PrimaryDesk / *SecondaryDesk / Not Spec.
2: All / CR / *ST1 / ST2 / *ST3
3: string
Active if the last loaded Global Snapshot is the one with the
name specified by ‘string’
OutputRoutingOut
1: Partial Output Routing
Active if the cross points of the specified partial output routing
are set as specified by ‘string’
ForwardInput
1: GP Input Pin Active if the specified input pin is active
ChannelUserKey
1: Logical Input | Master
2: User Function 1 | User Function 2
Active if the value of the specified user key parameter is true.
If a channel user key on the desk (e.g. Fader Module) is assigned
to a Channel User Key parameter, and the ‘ChannelUserKey’ GPO
function connects that parameter to a GP output pin, the channel
user key can control the GPO.
PFL
1: LogicalInput / StripChannel /
MasterFaders / ExtPFL
2: PFL (CR) / *PFL ST1
Active if the speciîš¿ed input or master is assigned to the speci-
îš¿ed PFL bus
Generator
1: StaticHigh / StaticLow / Alternate
Creates the Level according to the mode specified by Argu-
ment 1.
StaticHigh: Level is always high
StaticLow: Level is always low
Alternate: Level is alternating (f is approx. 1 Hz)
LSPModeOnRedLight
1: CR / *ST1 / ST2 / *ST3
2: Dim / Cut / Nothing / Cut, but allow TB
Indicates LSPModeOnRedLight
* OnAir 3000 only.
