OnAir Digital Mixing Consoles
6-124  Conguration
Document generated: 10.10.14
SW V6.0
(Fader Module) (Rotary Module)
Key 2:
Key 1:
Function Name Rel. in SW Rotary Function Key 1 Function Key 2 Function
EQ_HF_Q_Only V4.0 EQ_HF_Q - -
EQ_HMF_Freq V1.0 EQ_HMF_Freq EQ_On/Off -
EQ_HMF_Freq_Only V4.0 EQ_HMF_Freq - -
EQ_HMF_Gain V1.0 EQ_HMF_Gain EQ_On/Off -
EQ_HMF_Gain_Only V4.0 EQ_HMF_Gain - -
EQ_HMF_Q V1.0 EQ_HMF_Q EQ_On/Off -
EQ_HMF_Q_Only V4.0 EQ_HMF_Q - -
* EQ_HP_Freq V2.0 EQ_HP_Freq EQ_On/Off EQ_HP_On/Off
* EQ_HP_Slope V2.0 EQ_HP_Slope EQ_On/Off EQ_HP_On/Off
EQ_LF_Freq V1.0 EQ_LF_Freq EQ_On/Off -
EQ_LF_Freq_Only V4.0 EQ_LF_Freq - -
EQ_LF_Gain V1.0 EQ_LF_Gain EQ_On/Off -
EQ_LF_Gain_Only V4.0 EQ_LF_Gain - -
EQ_LF_Q V1.0 EQ_LF_Q EQ_On/Off -
EQ_LF_Q_Only V4.0 EQ_LF_Q - -
EQ_LMF_Freq V1.0 EQ_LMF_Freq EQ_On/Off -
EQ_LMF_Freq_Only V4.0 EQ_LMF_Freq - -
EQ_LMF_Gain V1.0 EQ_LMF_Gain EQ_On/Off -
EQ_LMF_Gain_Only V4.0 EQ_LMF_Gain - -
EQ_LMF_Q V1.0 EQ_LMF_Q EQ_On/Off -
EQ_LMF_Q_Only V4.0 EQ_LMF_Q - -
* EQ_LP_Freq V2.0 EQ_LP_Freq EQ_On/Off EQ_LP_On/Off
* EQ_LP_Slope V2.0 EQ_LP_Slope EQ_On/Off EQ_LP_On/Off
Exp_Attack V1.0 Exp_Attack_Time Dyn_On/Off Exp_On/Off
Exp_Attack_Only V4.0 Exp_Attack_Time - -
Exp_Ratio V1.0 Exp_Ratio Dyn_On/Off Exp_On/Off
Exp_Ratio_Only V4.0 Exp_Ratio - -
Exp_Release V1.0 Exp_Release_Time Dyn_On/Off Exp_On/Off
Exp_Release_Only V4.0 Exp_Release_Time - -
Exp_Threshold V1.0 Exp_Threshold Dyn_On/Off Exp_On/Off
Exp_Threshold_ExpOn V4.0 Exp_Threshold Exp_On/Off -
Fader V3.1 Fader_Gain Channel_On/Off PFL_On/Off
Gain/Cal V1.0 MicGain_Cal - -
Gate_Attack V1.0 Gate_Attack_Time Dyn_On/Off Gate_On/Off
Gate_Attack_Only V4.0 Gate_Attack_Time - -
Gate_Attenuation V1.0 Gate_Attenuation Dyn_On/Off Gate_On/Off
Gate_Attenuation_Only V4.0 Gate_Attenuation - -
Gate_Release V1.0 Gate_Release_Time Dyn_On/Off Gate_On/Off
Gate_Release_Only V4.0 Gate_Release_Time - -
Gate_Threshold V1.0 Gate_Threshold Dyn_On/Off Gate_On/Off
Gate_Threshold_GateOn V4.0 Gate_Threshold Gate_On/Off -
InputSelect V1.0 InputSelect InputSelectEnter -
Lim_Attack V1.0 Lim_Attack_Time Dyn_On/Off Lim_On/Off
Lim_Attack_Only V4.0 Lim_Attack_Time - -
Lim_Release V1.0 Lim_Release_Time Dyn_On/Off Lim_On/Off
Lim_Release_Only V4.0 Lim_Release_Time - -
Lim_Threshold V1.0 Lim_Threshold Dyn_On/Off Lim_On/Off
Lim_Threshold_LimOn V4.0 Lim_Threshold Lim_On/Off -
