OnAir Digital Mixing Consoles
Conguration  6-125
Document generated: 10.10.14
SW V6.0
(Fader Module) (Rotary Module)
Key 2:
Key 1:
Function Name Rel. in SW Rotary Function Key 1 Function Key 2 Function
* NXBus1...16 Level (** 1-8) V1.0 NXBus1...16 Level NXBus1...16 OnOff -
* NXBus1...16 LevelOnly (** 1-8) V1.0 NXBus1...16 Level - -
* NXBus1...16ContrLevel (** 1-8) V2.1 NXContr1...16Level NXContr1...16OnOff -
* NXBus1...16ContrLevelFullReturn
(** 1-8)
V2.1 NXContr1...16Level
NX***
FullReturn1...16OnOff
-
* NXBus1...16ContrLevelOnly (** 1-8) V2.1 NXContr1...16Level - -
* NXBus1...16LevelFullReturn (** 1-8) V2.1 NXBus1...16 Level
NXBus1...16
OnOffFullRet
-
* NXBus17...48 Level V3.2 NXBus17...48 Level NXBus17...48 OnOff -
* NXBus17...48 LevelOnly V3.2 NXBus17...48 Level - -
* NXBus17...48ContrLevel V3.2 NXContr17...48Level NXContr17...48OnOff -
* NXBus17...48ContrLevelFullReturn V3.2 NXContr17...48Level
NX***FullReturn17...48
OnOff
-
* NXBus17...48ContrLevelOnly V3.2 NXContr17...48Level - -
* NXBus17...48LevelFullReturn V3.2 NXBus17...48 Level
NXBus17...48
OnOffFullRet
-
NXSend V1.0 NXMasterGain NX***MasterOnOff -
NXSendCue V2.2 NXMasterGain NX***MasterCueOnOff -
NXSendLevelOnly V1.0 NXMasterGain - -
CueToNXMode V5.0 - CueToNXMode -
PGMA_OnOff V2.0 - PGMBusAOnOff -
* PGMB_OnOff V2.0 - PGMBusBOnOff -
Rec_OnOff V2.0 - RecBusOnOff -
* SubGroup1_OnOff V2.0 - SubGroup1OnOff -
* SubGroup2_OnOff V2.0 - SubGroup2OnOff -
* SubGroup3_OnOff V2.0 - SubGroup3OnOff -
* SubGroup4_OnOff V2.0 - SubGroup4OnOff -
* SubGroup5_OnOff V2.0 - SubGroup5OnOff -
* SubGroup6_OnOff V2.0 - SubGroup6OnOff -
* SubGroup7_OnOff V2.0 - SubGroup7OnOff -
* SubGroup8_OnOff V2.0 - SubGroup8OnOff -
* Group_VCA1_2_OnOff V3.2 - SubGroup2OnOff SubGroup1OnOff
* Group_VCA3_4_OnOff V3.2 - SubGroup4OnOff SubGroup3OnOff
* Group_VCA5_6_OnOff V3.2 - SubGroup6OnOff SubGroup5OnOff
* Group_VCA7_8_OnOff V3.2 - SubGroup8OnOff SubGroup7OnOff
* Sur51BusA V2.2 - Sur51BusAOnOff_Rotary -
* Sur51BusB V2.2 - Sur51BusBOnOff_Rotary -
TimerSelectA..D V2.1 - TimerSelectA..D -
VoiceMix1...4 (** 1) V6.0 Weight_IfVmix1...4Assigned VoiceMix1...4_Assign -
Weight V6.0 Weight - -
* not supported by OnAir 1500/2500
** supported by OnAir 1500/2500
*** of the N–X bus controlled by the corresponding logical input
