Studer OnAir 3000 User Manual

OnAir Digital Mixing Consoles
6-128 Conguration
Document generated: 10.10.14
SW V6.0
Function Assignable to: Details
Rel.
in
SW
Key Group Key Unit LED Display Display Module Rotary Unit
PFL Speaker
MonPFLSPVol V4.0 ●
sets either the PFLSpeaker Vol (default),
TBReturnVol, MPX Vol or HPSplitBalance depends
on the MonSetTBRetVol, MonSetMPXVol and
MonSetHPSplitBal functions.
MonPFLSPVol_CR / _S1 V4.0 ●
MonSetHPSplitBal V4.0 ●
assign the HPSplitBalance to the MonPFLSPVol control,
key in momentary mode
MonSetHPSplitBal_CR / _S1 V4.0 ●
MonSetHPSplitBal_LO V4.0 ●
assign the HPSplitBalance to the MonPFLSPVol control,
key in latching mode
MonSetHPSplitBal_CR_LO /
_S1_LO
V4.0 ●
MonSetMPXVol V4.0 ●
assign the MPX-Vol to the MonPFLSPVol control, key in
momentary mode
MonSetMPXVol_CR / _S1 V4.0 ●
MonSetMPXVol_LO V4.0 ●
assign the MPX-Vol to the MonPFLSPVol control, key in
latching mode
MonSetMPXVol_CR_LO / _S1_LO V4.0 ●
MonSetTBRetVol V4.0 ●
assign the TBReturnVol to the MonPFLSPVol control, key
in momentary mode
MonSetTBRetVol_CR / _S1 V4.0 ●
MonSetMPXVol_LO V4.0 ●
assign the MPX-Vol to the MonPFLSPVol control, key in
latching mode
MonSetMPXVol_CR_LO / _S1_LO V4.0 ●
NeareldPFL V4.0 ●
switches the monitoring mode between mode I and mode
II
NeareldPFL_CR / _S1 V2.0 ●
DJ HP
MonHPDJMode V4.0 ●
assign to a KeyGroup: Key 0=CR MON, 1=CR MON/PFL,
2=PFL
MonHPDJMode_CR / _S1 V4.0 ●
MonHPDJSplitMode V4.0 ●
switches the split mode of the DJ HP between 'MON' and
'PFL'
MonHPDJVol V4.0 ●
sets either the HPVolume (default) or HPSplitBalance
depends on the MonSetHPSplitBalToHPVol function
MonHPDJVol_CR / _S1…3 V4.0 ●
ResetMonHPDJVol V4.0 ●
ResetMonHPDJVol_CR / _S1…3 V4.0 ●
MonSetHPSplitBalToHPVol V4.0 ●
assign the HPSplitBalance to the MonHPDJVol control,
key in momentary mode
MonSetHPSplitBalToHPVol_LO V4.0 ●
assign the HPSplitBalance to the MonHPDJVol control,
key in latching mode
MonSetHPSplitBalToHPVol_S1 V4.0 ●
MonSetHPSplitBalToHPVol_S1_LO V4.0 ●
MonSetPFLVolToHPVol V4.0 ●
assign the PFL volume to the MonHPDJVol control, key
in momentary mode
MonSetPFLVolToHPVol_LO V4.0 ●
assign the PFL volume to the MonHPDJVol control, key
in latching mode
